Product Description

············This link price is only for DDSU1589···········

Product Overview The DDSU1589(1P)single-phase electronic energy meter adoptssingle-chip control.It has the characteristics of few peripheralcomponents,simple structure,high reliability,low power consumption,and long lifespan.It can be used to measure single-phase AC activeenergy with a rated frequency of 50Hz.The performance parametersof this product meet all the technical requirements for single-phaseelectronic energy meters in the GB/T17215.321-2008 "Class 1 and Class 2 Static AC Active Energy Meters"standard. Features 1.Measurement of active energy without the need for calibration. 2.Uses the specialized measuring chip ADE7755. 3.Uses the latest specialized integrated circuit with a digital remainderalgorithm,greatly improving the dynamic working range of themeter and achieving an actual overload capacity of more than 10times. 4.Good error linearity within the range of 5%lb~lmax. 5.Few peripheral components,low power consumption,and simplemeter structure. 6.All components inside the meter are selected for long lifespan andhigh reliability. 7.Display mode:LCD. 8.Equipped with remote power disconnection function. 9.Output interface:RS485.

Rated Voltage	Rated Current	Rated Frequency	Accuracy Level
220V or 240V	5(20)A;5(32)A;5(65)A;10(40)A;10(60)A;15(60)A;	50Hz or 60Hz	Class 1 or Class 2

Geya is a high-tech private enterprise focusing on the independent research and development of low-voltage electrical appliances and automation control intelligent products.High-tech enterprise in Zhejiang Province.The company's sales revenue has reached over 100 million RMB in 2023.Comprehensively advancing towards automated production. Continuously meeting customer delivery requirements.Our primary task is to meet customer needs. We will deliver products with zero defects in a timely manner.Our main categories are low-voltage products, industrial control products, and photovoltaic products, such as relays, circuit breakers, and DC fuses.All types of certificates are complete, such as CE CB, etc.

Q:What advantages do you have? A: GEYA is the direct Mlanufacturer in Wenzhou China from 2007, we have professional developing, marketing & production team to offer you the most competitive price and best service. Q: What's your main product? A: We have two product projects, low voltage electrical and automation control items Q: Could you print our own logo? A: Yes, Our company is available for Retail & Wholesale & OEM & ODM. Q: How long is the product guarantee? A: 18 month warranty, have QC department in charge of the products quality, our products are 100% inspection. Q:What is your quality control process? A: The quality of our production depends on all the components and therefore when selecting our suppliers we have to pay more attention to the quality of the raw material supplied. To prevent possible errors we perform testing at different levels and intemmediate stages of the product production phases. Q: How long is the delivery time? A: lt usually takes about 3 - 5 working days for sample order and 10 - 25 days for big order. Q: What is your payment term? A: Our Payment term is T/T, Aliexpress, Western Union, PayPal, Money Gram, L/C at sight. Q: Any certification of your company or product? A: We have ISO 9001.CE.CB.SEMKO,SAA.TUV.CCC， ROHS
