GEYA Dc Mcb Circuit Breaker 1P 2P 3P 4P Mini Miniature 16a 25amp 63a for Solar PV System 4.5ka DC1000V DC500V DC750V

GEYA Dc Mcb Circuit Breaker 1P 2P 3P 4P Mini Miniature 16a 25amp 63a for Solar PV System 4.5ka DC1000V DC500V DC750V

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Dc Mcb Circuit Breaker 1p 2p 3p 4p Mini Miniature 16a 25amp 63a For Solar Pv System 4.5ka Dc1000v Dc500v Dc750v - Buy Disjuntor Dc Breaker Solar Pv Breaker Dc Mcb Solar 1000vdc Solar System Solar Panel Breaker 2v Mcb Dc Disyuntor Dc Solar Pv Breaker solar Photovoltaic 1000v 32a Dc Circuit Breaker Mcb Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

·········This link price is only for GYM10H-4.5kA-DC 3P 10-25A········
Functions and Applications：
Overload, short circuit, isolation; Suitable for communication, photovoltaic and other DCsystem applications.
Product Feature：
Contact Position Indication Function Maximum Wiring Capacity 25mm²
GEYA Dc Mcb Circuit Breaker 1P 2P 3P 4P Mini Miniature 16a 25amp 63a for Solar PV System 4.5ka DC1000V DC500V DC750V
GEYA Dc Mcb Circuit Breaker 1P 2P 3P 4P Mini Miniature 16a 25amp 63a for Solar PV System 4.5ka DC1000V DC500V DC750V
GEYA Dc Mcb Circuit Breaker 1P 2P 3P 4P Mini Miniature 16a 25amp 63a for Solar PV System 4.5ka DC1000V DC500V DC750V
GEYA Dc Mcb Circuit Breaker 1P 2P 3P 4P Mini Miniature 16a 25amp 63a for Solar PV System 4.5ka DC1000V DC500V DC750V
Technical Specification
Standard
IEC/EN60947-2、GB/T 14048.2
rated Current(In)
6、10,16、20、25、32、40、50、63A
Rated Voltage(Ue)
1P:250VDC;2P:500VDC; 3P;750VDC;4P:1000VDC;
Tripping Curves
li=8.5In(Trip type C),li=12In(Trip type D)
Breaking Capacity
4500A
Poles
1P、2P、3P、4P
mechanical Life
20000 time
rated insulation voltage (Ui)
500V
rated impulse withstand voltage (Uimp)
4kV
