Product Description

···········This link price is only for GY-XLP-160/29···········

Product Description： GY-XLP fuse-type isolating switches(hereinafter referred to as switches)aresuitable for AC 50/60Hz rated voltage to DC500VIAC690V and agreed heatingcurrent to 800A in distribution circuits and motor circuits with high short-circuitcurrent as power switches and isolating switches.,emergency switch,and used forcircuit protection,but generally not used to directly switch a single motor.It can alsobe used as a knife switch.

Mode			160							250
Number of poles			2P							2P
Rated operating voltage Ue AC (V)					500	690		500	690
Rated operating voltage Ue DC(V)			220	500	一		500
Rated operating current le(A)			160	100	160	100	250	250	200
Fuse thermal overload current (A)			160	160	160	160	250	250	250
Usage categories			DC22B	DC22B	AC22B	AC21B	DC22B	AC22B	AC21B
Rated insulation voltage Ui (kV)			1000							1000
Rated impact withstand voltage Uimp (kV)			8							8
Rated limited short-circuit current (kA)			50							50
Rated frequency (Hz)			50/60							50/60
Single phase power loss (W)			3.5							7.5
Electrical life			200							200
Mechanical life			1400							1400
Front protection level according to IEC60529	Open	IP20							IP20
Front protection level according to IEC60529		Closure	IP30							IP30

Geya is a high-tech private enterprise focusing on the independent research and development of low-voltage electrical appliances and automation control intelligent products.High-tech enterprise in Zhejiang Province.The company's sales revenue has reached over 100 million RMB in 2023.Comprehensively advancing towards automated production. Continuously meeting customer delivery requirements.Our primary task is to meet customer needs. We will deliver products with zero defects in a timely manner.Our main categories are low-voltage products, industrial control products, and photovoltaic products, such as relays, circuit breakers, and DC fuses.All types of certificates are complete, such as CE CB, etc.
