Home > Products > Circuit Breaker > GEYA GYH8 CE CB 230V/400V 32A 40A 50A 63A 1P 2P 3P 4P Isolating air Isolator Main Switch Cheap air Main Switch
GEYA GYH8 CE CB 230V/400V 32A 40A 50A 63A 1P 2P 3P 4P Isolating air Isolator Main Switch Cheap air Main Switch

GEYA GYH8 CE CB 230V/400V 32A 40A 50A 63A 1P 2P 3P 4P Isolating air Isolator Main Switch Cheap air Main Switch

#detail_decorate_root .magic-0{width:750px}#detail_decorate_root .magic-1{overflow:hidden;width:750px;height:2129.408713692946px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-2{margin-top:0;margin-left:0;width:750.0000000000001px;height:2129.408713692946px}#d......Keywords:Geya Gyh8 Ce Cb 230v/400v 32a 40a 50a 63a 1p 2p 3p 4p Isolating Air Isolator Main Switch Cheap Air Main Switch - Buy Isolator Main Switch air Switch safety Switch Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

GEYA GYH8 CE CB 230V/400V 32A 40A 50A 63A 1P 2P 3P 4P Isolating air Isolator Main Switch Cheap air Main Switch
·················This link price is only for GYH8 1P-16-63A················

As the main switch in the combination of electrical terminal apparatus,GYH8 isolator is sultable for circuit of 50Hz,rated voltage 230V/400V,rated current up to 125A for iso-lating,it also can be used for infrequent on-and-off clrc-ult,and is widely used in industry,mine,high-building,commerce and household and so on.

In conformity to IEC/EN60947-3
Double-point direct-moving srtucure
With indicator function in the contact position
Bilateral busbar wiring capabilities to adapt to the wider use of premises
Maximum connecting ability of 35/50mm2,wiring torque 3.5N*m,applicable to a variety of installing equipments,wiring stronger.
Protection class:IP20
GEYA GYH8 CE CB 230V/400V 32A 40A 50A 63A 1P 2P 3P 4P Isolating air Isolator Main Switch Cheap air Main Switch
Product Name
GYH8 Isolator Main Switch
Rated Current In
32A 40A 50A 63A 100A 125A
Poles
1P 2P 3P 4P
Rated Voltage Ue
1P: 230/400V 2P/3P/4P: 400V
Insulation Voltage Ui
500V
Rated Frequency
50/60Hz
Using the categories
AC-22A
Electrical Life
1500
Mechanical Life
8500
Protection Degree
IP20
Certificate
CE CB SEMKO SAA CCC TUV
Guarantee
2YEARS
