Home > Products > Transfer Switch > GEYA GYHO8-125 4P Manual Changeover MCB DIN Rail Mounting Modular Disconnecting Transfer Switch
GEYA GYHO8-125 4P Manual Changeover MCB DIN Rail Mounting Modular Disconnecting Transfer Switch

GEYA GYHO8-125 4P Manual Changeover MCB DIN Rail Mounting Modular Disconnecting Transfer Switch

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Gyho8-125 4p Manual Changeover Mcb Din Rail Mounting Modular Disconnecting Transfer Switch - Buy 4 Pole Power Change Over Switch Dual Power Transfer Switch Ats 2p 63a 230v Mcb Type generator Dual Power Transfer Switch 4p 400v 100a Ats Changeover Switch 63a 110v/220v Mini Ats 32a 2p Ats Controller Generator 3 Pole Auto Dual Power Transfer Switch Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

········This link price is only for GYHO8-125 4P Red Copper 85 Silver Dot.······
13.5mm Modular ISOLATOR LND-125 was designed according to IEC 60947-3.It meets thedemand of loading and isolating the circuit.It is used as a main switch in distribution boxesin household applications or as a switch for individual electric circuits,easily to be assembledand work with the same series compact circuit breakers together.
GEYA GYHO8-125 4P Manual Changeover MCB DIN Rail Mounting Modular Disconnecting Transfer Switch
GEYA GYHO8-125 4P Manual Changeover MCB DIN Rail Mounting Modular Disconnecting Transfer Switch
Rated current
25,40,63,80,100,125A
Rated voltage
230/400VAC
Frequency
50/60 Hz
Rated insulation voltage Ui
400V
Rated impulse withstand voltage Uimp
6KV
Rated short-circuit making capacity
Icm 1.5KA
Rated short time withstand current Icw
1.5KA
Mechanical endurance
≥8,500 operating cycles
Electrical endurance
≥1,500 operating cycles
Type
Specifical
PCS/CTN
Inner box size
(CM)
Carton Size
(CM)
K.W.
(KG)
N.W.
(KG)
GYHO8
1P 16A-50A Brass alloy Red copper alloy contact
240
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
1P 63A-125A Red copper alloy Red copper alloy contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 16A-50A Brass alloy Red copper alloy contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 63A-125A Red copper alloy Red copper alloy contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 16A-50A Brass alloy Red copper alloy contact
80
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 63A-125A Red copper alloy Red copper alloy contact
40
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 16A-50A Brass alloy Red copper alloy contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 63A-125A Red copper alloy contact
30
289*90*80
47*30*26
19.5
18.3
GYHO8
1P 16A-50A Red Copper silver contact
240
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
1P 63A-125A Red Copper 85% Silver Contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 16A-50A Red Copper silver contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 63A-125A Red Copper 85% Silver Contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 16A-50A Red Copper silver contact
80
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 63A-125A Red Copper 85% Silver Contact
40
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 16A-50A Red Copper silver contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 63A-125A Red Copper 85% Silver Contact
30
289*90*80
47*30*26
19.5
18.3
