Product Description

········This link price is only for GYHO8-63 2P Red Copper Alloy Point······
Modular manual changeover switches are a unique solution that has a three-stable position switch I-0-ll to allow you to control two power supply sources.
GEYA GYHO8-63 2P Changeover Switch 2p 63a 230/400vac Modular Dual Power Manual Transfer Switch PC Rail Switch 3 Poles 32a 63 ZHE
GEYA GYHO8-63 2P Changeover Switch 2p 63a 230/400vac Modular Dual Power Manual Transfer Switch PC Rail Switch 3 Poles 32a 63 ZHE
GEYA GYHO8-63 2P Changeover Switch 2p 63a 230/400vac Modular Dual Power Manual Transfer Switch PC Rail Switch 3 Poles 32a 63 ZHE
GEYA GYHO8-63 2P Changeover Switch 2p 63a 230/400vac Modular Dual Power Manual Transfer Switch PC Rail Switch 3 Poles 32a 63 ZHE
Rated Voltage
240/415V~
Rated Current
16,25,32,40,63,80A
Rated Frequency
50/60Hz
Number of Poles
1,2,3,4P
Contact form
l-O-II
Electrical Life
1500 Cycles
Mechanical Life
10000 Cycles
Protection degree
IP20
Ambient Temperature
-5℃ to 40℃
Terminal/Cable size
25mm²
Installation
Mounting on 35mm DIN rail
Type
Specifical
PCS/CTN
Inner box size
(CM)
Carton Size
(CM)
K.W.
(KG)
N.W.
(KG)
GYHO8
1P 16A-50A Brass alloy Red copper alloy contact
240
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
1P 63A-125A Red copper alloy Red copper alloy contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 16A-50A Brass alloy Red copper alloy contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 63A-125A Red copper alloy Red copper alloy contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 16A-50A Brass alloy Red copper alloy contact
80
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 63A-125A Red copper alloy Red copper alloy contact
40
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 16A-50A Brass alloy Red copper alloy contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 63A-125A Red copper alloy contact
30
289*90*80
47*30*26
19.5
18.3
GYHO8
1P 16A-50A Red Copper silver contact
240
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
1P 63A-125A Red Copper 85% Silver Contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 16A-50A Red Copper silver contact
120
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
2P 63A-125A Red Copper 85% Silver Contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 16A-50A Red Copper silver contact
80
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
3P 63A-125A Red Copper 85% Silver Contact
40
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 16A-50A Red Copper silver contact
60
220*90*80
46.5*23.5*34.5
19.5
18.3
GYHO8
4P 63A-125A Red Copper 85% Silver Contact
30
289*90*80
47*30*26
19.5
18.3
