GEYA 10a Solid State Relay Ssr 3 Phase Relay Dust Proof Ac Control for Heating Machine

GEYA 10a Solid State Relay Ssr 3 Phase Relay Dust Proof Ac Control for Heating Machine

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya 10a Solid State Relay Ssr 3 Phase Relay Dust Proof Ac Control For Heating Machine - Buy Solid State Relay Ssr 3-phase ac Control Solid State Relay 10a controller For Electric Heaters Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

············This link price is only for VTG10DA48Z···········
Features ·Three-pole,single-throw,one normally open,suitable for three-phase loads ·Rated off-state voltage:480Vrms;530Vrms ·The switch type is zero-crossing conduction type and random conduction type ·Input control voltage:3-32Vdc,AC 90-280Vac ·Good thermal performance and long life ·Rated on-state current:3x25-150A ·Input/output insulation voltage: 2500Vrms ·LED input display
GEYA 10a Solid State Relay Ssr 3 Phase Relay Dust Proof Ac Control for Heating Machine
GEYA 10a Solid State Relay Ssr 3 Phase Relay Dust Proof Ac Control for Heating Machine
GEYA 10a Solid State Relay Ssr 3 Phase Relay Dust Proof Ac Control for Heating Machine
Output Parameter
Units
Specification Limits
Model No.:VTG
Amps
25
40
60
80
100
120
150
Load Current Range
Arms
3x25
3x 40
3x60
3x80
3x100
3x120
3x150
Surge Current 20mSec [Max.]
Arms
300
400
600
800
1000
1200
1500
Load Voltage Range [480V]
Vrms
48 to 480
Transient Overvoltage [480V]
Vpk
≥1200
Load Voltage Range [530V]
Vrms
53 to 530
Transient Overvoltage [530V]
Vpk
≥1400
Frequency Range
Hz
47 to 63
Off State dv/dt [Min.]
V/usec
500
Off State Leakage Current [Max.]
mArms
≤8
On State Voltage Drop [Max.]
Vrms
1.8
Thermal Resistance,[Rthjc]
℃/W
0.75
0.55
0.46
0.38
0.34
0.23
0.23
Turn on Time [Max.]“Z”
Cycle
1/2
Turn off Time [Max.]“D”
Cycle
1/2
Turn on Time [Max.]“R”
mSec
1
Turn off Time [Max.]“A”
mSec
10
