GEYA ACB Intelligent Universal Circuit Breaker for Ac Acb China Drawout 3p 800 Amp 3p Acb 800a

GEYA ACB Intelligent Universal Circuit Breaker for Ac Acb China Drawout 3p 800 Amp 3p Acb 800a

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Acb Intelligent Universal Circuit Breaker For Ac Acb China Drawout 3p 800 Amp 3p Acb 800a - Buy 3 4 Phase Drawer Type Electrical Acb Air Circuit Breakers drawer Universal Circuit Breaker electrical Acb Breaker Momentary Circuit Breaker universal Air Circuit Breaker Price Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

············This link price is only for GYNV-1600 3P 200-800A·········
GYNV-1600 integrated circuit breaker is one of the new types of circuit breakers developed using advanced technology. This product is suitable for general distribution systems and new energy applications In scenarios such as power distribution systems, multi energy distribution networks, inverters, and distributed power sources for rotating electrical machines, it has multiple functional characteristics such as isolation function, small size, high breaking capacity, etc.
GEYA ACB Intelligent Universal Circuit Breaker for Ac Acb China Drawout 3p 800 Amp 3p Acb 800a
GEYA ACB Intelligent Universal Circuit Breaker for Ac Acb China Drawout 3p 800 Amp 3p Acb 800a
Model
1600
Shell level rated current Inm (A)
1600
Rated current In (A)
200、400、630、800、
1000、1250、1600
Rated working voltage Ue (V)
AC50Hz 400V 800V
Rated insulation voltage Ui (V)
1000
Rated impulse withstand voltage Uimp (kV)
12
Power frequency withstand voltage U (V) for 1 minute
3500
Pole number
3、4
N-pole rated current In (A)
100%ln
Usage category
GB/T14048.2
B
GB/T14048.4(In≤1000A)
AC-3
Rated ultimate short-circuit breaking capacity
Lcu (kA) (effective value)
AC400V
60
AC800V
32
Rated operating short-circuit breaking capacity
Lcs (kA) (effective value)
AC400V
50
AC800V
20
Rated short-time making capacity
Lem (kA) (peak value)
AC400V
143
AC800V
105
Rated short-time withstand current
(1s) lcw (kA) (effective value)
AC400V
50
AC800V
20
Full break time (without additional delay) (ms)
25
Closing time (ms)
Maximum 70
Electrical lifespan (times)
AC400V
Maintenance free 1500
Maintenance free 4500
AC800V
Maintenance free 1200
Maintenance 3500
Mechanical lifespan (times)
Maintenance free
4500
Maintenance
8500
