Technical Parameters | ||
Compliant with | IEC/EN62606、IEC/EN61009-1、GB/T31143、GB16917.1 | |
Rated voltage Ue | 230V~ | |
Rated insulation voltage Ui | 400V | |
Rated impulse withstand voltage Uimp | 4kV | |
Rated current (A) | 6, 10, 16, 20, 25, 32, 40 | |
Pole number | 1P+N | |
Instantaneous trip | type C | |
Breaking capacity | 6kA | |
Rated residual current (mA) | 30, 100, 300 | |
Operating characteristics when the residual current has DC component | type AC, type A |
