Product Description

················This link price is only for GYL9-B-30mA 32-40A 4P·················

GEYA B Type RCCB Residual Current Circuit Breaker DC ELCB 2P 63 Amp 30mA Type B 10KA RCD


***It is B type RCCB 2P 63A 30mA***
Type B RCCBs, in addition to normal AC, can detect high frequency AC and pure DC earth leakage currents. Reducing the risk of fire and/or electrocution through automatic disconnection of the electrical supply relies on the selection of the correct type of RCCB.

Application Example
EV & PV installations
Frequency converters
UPS installations
High-frequency power converters
Building site power supply cabinets


1.1 Function
 Control electric circuits.
Protect people against indirect contacts and additionalprotection against direct contacts.
Protect installations against fire hazard due to insulation faults.Residual current circuit breakers are used in housing, tertiarysector and industry
1.2 Selection
 Detectable wave form
B class
Tripping is ensured for sinusoidal AC residual currents pulsed DCresidual currents, alternatingresidual sinusoidal currents up to1000Hz, pulsating direct residual currents and for smooth directresidual currents, whether applied suddenly or increasing slowly.
Tripping sensitivity
 30mA -additional protection against direct contact.
Tripping time
Instantaneous
 It ensures instantaneous tripping (without time- delay).
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
GEYA Arc Fault 24v Miniature air 48v Dc Vacuum 16a Ac Circuit Breaker Mccb case Rccb Mcb Smart Doma41 Circuit Breaker 2p Lockout
Specification
Description
PCS/CTN
Carton Size
(CM)
G.W.
(KG)
N.W.
(KG)
16-25A
GYL9-B 2P 30mA AC
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
16-25A
GYL9-B 2P 100mA AC
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
16-25A
GYL9-B 2P 300mA AC
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
16-25A
GYL9-B 4P 30mA
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
16-25A
GYL9-B 4P 100mA
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
80A
50
49*40*17.5
20
19
100A
50
49*40*17.5
20
19
16-25A
GYL9-B 4P 300mA
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
80A
50
49*40*17.5
20
19
100A
50
49*40*17.5
20
19
