GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC

GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya G2r 50a 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type To Generator Ats 63a Switch 230v Ac - Buy Geya Ats 2p Ats automatic Transfer Switching(ats) ats Switch Automatic Transfer Super Fast automatic Transfer Switch Ats 50a 2p Ats Dual Prower Automatic Transfer Switch Changeover Switches Din Rail Type Generator Ats 63a Switch 220v Ac Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

This link price is only for G2R 2P 220V 50A.
G2R-63 automatic transfer switch is a PC class infrequent change-over switch,withtwo-station design_(commonly used for A and standby for B),suitable for ACsystems with AC 50-60hz and rated current 6A-63A.The main function oftheautomatic transfer switch is when the main power (common power supply A)fails,the ATS will automatically switch to the backup power(Backup power supply B)tocontinue working (switching speed <50 milliseconds),which can effectively solvethe troubles caused by power outages
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
Application:
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
GEYA G2R 50A 2p Ats Dual Ats Automatic Transfer Switch Changeover Switches Din Rail Type to Generator Ats 63A Switch 230V AC
63
Rated operating current le(A)
06A
10A
16A
20A
25A
Rated insulation voltage UI
690V
Rated working voltage Ue
AC220V/AC110V
Rated frequency
50160Hz
Class
PC class:can be switched on and loaded without generating short-circuit current
Rated short-circuit current lq
5kA
Short circuit protection device (fuse)
RT16-00-63A
Rated impulse withstand voltage
8kV
Control circuit
Rated control voltage Us:AC220V/110V,50/60Hz
Normal working conditions:85%Us-110%Us
Auxiliary circuit
AC220V/110V 50/60Hz le=5A
Overvoltage/undervoltage protection range
220V/50Hz Undervoltage value:175V Recovery value:195V.
Overvoltage value:260V Recovery value:240V (±5V)
110V/50Hz Undervoltage value:85V Recovery value:95V
Overvoltage value:145V Recovery value:130(±5V)
Mechanical life
≥8000 times
Electrical life
≥1500 times
Usage category
AC-31B
Pole number
2P
Rated impulse withstand voltage Uimp
8kV
Items
Specifical
PCS/CTN
Inner box size
(CM)
Carton Size
(CM)
K.W.
(KG)
N.W.
(KG)
G2R-63Ⅱ 2P
63A
48
1.2*5.5*8.5
46*25.5*27
18.96
19.5
G2R-63Ⅱ 4P
63A
30
12*9*85
46*25.5*27
17.7
18.2
