GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker

GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Grt6-b1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay On Off Delay Relay Breaker - Buy Time On Duration Relay Adjustable Low Voltage Relay Electronic Timer Relay Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

············This link price is only for GRT6-B1 A230············
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
GEYA GRT6-B1 A230 Time Relay 220v Voltage Control Single Shot Modular Timer Relay on Off Delay Relay Breaker
Technical parameters
GRT6-A1/B1
GRT6-A2/B2
GRT6-At/Bt
Function
A:delay ON;B:delay OFF
Supply terminals
A1-A2
Voltage range
AC/DC24-240V(50-60Hz)
Burden
AC 0.09-3VA/DC 0.05-1.7W
Voltage range
AC 230V(50-60Hz)
Power input
AC max.6VA/1.3W
AC max.6VA/1.9W
Supply voltage tolerance
-15%;+10%
Supply indication
green LED
Time ranges
0.1s-10days,ON,OFF
Time setting
potentionmete
Time deviation
10%-mechanical setting
Repeat accuracy
0.2%-set value stability
Temperature coecient
0.05%/℃,at=20℃(0.05%F,at=68F)
Output
1×SPDT
2×SPDT
1xSPDT(del)+1xSPDT(ins)
Currentrating
10A/AC1
Switching voltage
250VAC/24VDC
Min.breaking capacity DC
500mW
Output indication
red LFD
Mechanical life
1×10^7
Electrical life(AC1)
1×10^5
Reset time
max.200ms
Operating temperature
-20℃ to +55℃(-4F to 131F)
Storage temperature
35℃ to+75℃(-22F to 158F)
Mounting/DIN rail
Din rail EN/IEC 60715
Protection degree
IP40 for front panel/IP20 terminals
Operating position
any
Overvoltage cathegory
III
Pollution degree
2
Max.cable size(mm)
solid wire max.1x2.5or2×1.5/with sleeve max.1x2.5(AWG 12)
Tightening torque
0.4Nm
Dimensions
90×18x64mm
Weight
S240-61g,A230-61g S240-81g,A230-80g
Standards
EN 61812-1,IEC60947-5-1
