Product Description

*****This link price is only for GRT8-EC-AC220V/DC24V*****
GEYA GRT8-EC-230 AC230V DC24V on Delay off Two Delay Modes Dual Function Time Relay
GEYA GRT8-EC-230 AC230V DC24V on Delay off Two Delay Modes Dual Function Time Relay
GEYA GRT8-EC-230 AC230V DC24V on Delay off Two Delay Modes Dual Function Time Relay
GEYA GRT8-EC-230 AC230V DC24V on Delay off Two Delay Modes Dual Function Time Relay
Applications
-Dual function time relay can be used for industrial equipment, lighting control, heating element control, motor and fan control,
with two delay modes, and the delay range covers 0.1 seconds to 10days.

Function Features
- Two delay modes can be set.
- Supports AC230V ,AC/DC24V two kinds of working voltage.
- Ultra wide delay range, 0.1 seconds - 10 days can be set..
- The working state of the relay is indicated by the LED indicator.
- Ultra small size, only 18mm width, 35mm rail installation.
GRT8-EC
Function
ON delay,Delay off
Supply terminals
A1-A2(AC230V,AC380V),A1-A3(AC/DC24V)
Voltage range
AC230V(50-60Hz)orAC/DC24V,AC380V(50-60Hz)
Power input
AC max.6VA/1.3W
Supply voltage tolerance
-15%;+10%
Supply indication
green LED
Time ranges
0.1s-10day
Time setting
potentionmeter
Time deviation
≤10%
Repeat accuracy
0.2%-set value stability
Temperature coefficient
0.05%/℃,at=20℃(0.05%°F, at=68°F)
output
1×SPDT
Current rating
1×10A(AC1)
Switching voltage
250VAC/24VDC
Min.breaking capacity DC
500mw
Output indication
red LED
Mechanical life
1×10^7
Electrical life(AC1)
1×10^5
Resettime
max.200ms
perating temperature
-20℃ to+55℃(-4°F to 131°F)
Storage temperature
-35℃to+75℃ (-22°F to 158°F)
Mounting/DIN rail
Din rail EN/IEC 60715
Protection degree
IP40 for front panel/IP20 terminals
Operating position
any
overvoltage cathegory
Ⅲ.
Pollution degree
2
Max.cable size(mm²)
solid wire max.1×2.5or 2×1.5/with sleeve max.1×2.5(AWG12)
Dimensions
90×18×64mm
Weight
52g
Standards
EN61812-1,IEC60947-5-1
