GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay

GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Grt8-m2 10 Functions Time Relay Time Switch On Delay Off Delay Cycler 2 Output Multifunction Relay - Buy 10 Function Time Relay digital Timer Switch multifunction Relay Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

···········This link price is only for GRT8-M2-AC230···········
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
GEYA GRT8-M2 10 Functions Time Relay Time Switch on Delay Off Delay Cycler 2 Output Multifunction Relay
Applications -Multifunction time relay can be used for electrical appliances, control of lights, heating, motors, pumps, and fans(10 functions, 10-time ranges, multi-voltage). Feature -10 functions: -5 time functions controlled by supply voltage -4 time functions controlled by control input -1 function of latching relay -Comfortable and well-arranged function and time range set by rotary switches. -Time scale 0.1 s-10 days divided into 10 ranges. -Relay status is indicated by LED. -1-MODULE, DIN rail mounting.
item
value
Place of Origin
China
Zhejiang
Brand Name
GEYA OEM ODM
Model Number
GRT8-M2-A230
Theory
Time Relay
Usage
PROTECTIVE
Size
Miniature
Protect Feature
Sealed
Contact Load
Low Power
Product name
Multi Function Time Relay
Voltage Range
AC/DC 12-240V or AC230V
Frequency
50/60HZ
Load Current
16A
Output
1SPDT OR 2 SPDT
Time Range
0.1s-10days ON OFF
Weight/pcs
1KG/PCS
Certifications
CE CB
Warranty/guarantee
18months
Item
Specification
N.W. of product (g)
G.W. of product (g)
Medium box weight
(g)
G.W. of 60pcs/CTN (kg)
G.W. of 100pcs/CTN(kg)±50g
G.W. of 200pcs/CTN(kg)
GRT8-M1/N1
A230
62.4
75.1
817
5.25
8.64
16.98
GRT8-M1/N1
AC/DC12V~240V
62.9
76.3
829
5.32
8.76
17.22
GRT8-M2/N2
A230
81.7
94.3
1009
6.40
10.56
20.82
GRT8-M2/N2
AC/DC12V~240V
82.6
95.4
1020
6.47
10.67
21.04
