GEYA GSR1-3-60DA Smart 60A Solid State Relay Single Phase SSR Switching DC to AC Heat Sink

GEYA GSR1-3-60DA Smart 60A Solid State Relay Single Phase SSR Switching DC to AC Heat Sink

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Gsr1-3-60da Smart 60a Solid State Relay Single Phase Ssr Switching Dc To Ac Heat Sink - Buy Solid State Relay dc Ac Solid State Relay 3-32vdc Input 90-480v Ac Output Electrical Equipment Solid State Relay Module Ssr Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

··········This link price is only for GSR1-3-60DA·········
GEYA GSR1-3-60DA Smart 60A Solid State Relay Single Phase SSR Switching DC to AC Heat Sink
GEYA GSR1-3-60DA Smart 60A Solid State Relay Single Phase SSR Switching DC to AC Heat Sink
GEYA GSR1-3-60DA Smart 60A Solid State Relay Single Phase SSR Switching DC to AC Heat Sink
GEYA GSR1-3-60DA Smart 60A Solid State Relay Single Phase SSR Switching DC to AC Heat Sink

SSR Working:

The control inputs are connected internally to an LED, which shines across an air gap to light sensors.The light sensor is connected to the transistors which open or close, supplying the relay's load with power.When a transistor is closed, current can flow freely through the relay, causing the load and power supply to be connected. When a transistor is open, almost all current is blocked, causing the load to become disconnected from the power supply. The pairing of an LED with light sensors is called an optocoupler, and is a common technique to link two parts of a circuit without a direct electrical connection.

SSRs perform the same job as Mechanical Relays, but have the following advantages:
**SSRs produce less electromagnetic interference than mechanical relays during operation. This is mostly due to the absence of a
phenomenon called contact arcing only present in mechanical relays, where the physical contacts of the relay tend to spark
internally while switching. The reduced interference can also be attributed to the fact that SSRs do not use electromagnets to
switch.
**The switch contacts of a mechanical relay will eventually wear down from arcing. An SSR will have a longer life because its
internals are purely digital. Properly used, they will last for millions of cycles.
**SSRs turn on and off faster than mechanical relays (≈1ms compared to ≈10ms).
**SSRs are less susceptible to physical vibrations than mechanical relays.
**Since the switch inside an SSR isn't a mechanical switch, it does not suffer from contact bounce and operatessilently.
GEYA GSR1-3-60DA Smart 60A Solid State Relay Single Phase SSR Switching DC to AC Heat Sink
GSR1-3-60DA

Load Current
60A
Load Voltage
90-480V AC
Control Voltage
3-32V DC
Control Current
DC15-35mA
On Voltage
≤1.3V
Off Leakage Current
≤2mA
On-Off Time
≤10mS
Dielectric Strength
Input-Output-Floor≥2500VAC
Insulation Resistance
1000MΩ/500V DC
Ambient Temoerature
-30~75℃
Mounting Methods
Bolt Fixing
The Work Instructions
LED
Item No.
Description
Product weight
/KG
Inner box quantity
PCS/CTN
(PCS)
Carton Size
(CM)
G.W.
(KG)
N.W.
(KG)
Three phase
GSR1-3-10DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-25DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-40DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-60DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-80DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-100DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-120DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-150DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-200DA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-10AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-25AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-40AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-60AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-80AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-100AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-120AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-150AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-200AA
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-10DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-25DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-40DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-60DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-80DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-100DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-120DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-150DD
three phase
0.285
1
50
44*24*25
15
14.25
GSR1-3-200DD
three phase
0.285
1
50
44*24*25
15
14.25
