Home > Products > Circuit Breaker > GEYA GYL8 CE CB Approved Factory Price Hot Sale 2 Pole Earth Leakage Circuit Breaker 63A
GEYA GYL8 CE CB Approved Factory Price Hot Sale 2 Pole Earth Leakage Circuit Breaker 63A

GEYA GYL8 CE CB Approved Factory Price Hot Sale 2 Pole Earth Leakage Circuit Breaker 63A

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Gyl8 Ce Cb Approved Factory Price Hot Sale 2 Pole Earth Leakage Circuit Breaker 63a - Buy 2 Pole Earth Leakage Circuit Breaker earth Leakage Circuit Breaker 63a circuit Breaker Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

············This link price is only for GYL8 2P 32-40A 100/300mA···········
GYL8 residual current circuit breaker (without overcurrent protection)is suitable for AC 50Hz, rated voltage 240V for two poles 415V for four poles, and rated current up to 63A.lt can quickly cut off the fault powerin very short time.

To protect the safety of people and electricalequipment, it can also be used for infrequentswitching of lines.

Compliant with: IEC61008-1,GB16916.1, CE,CBmarked.
GEYA GYL8 CE CB Approved Factory Price Hot Sale 2 Pole Earth Leakage Circuit Breaker 63A
Electrical features
Residual current protection type
Electromagnetic/Electronic
Residual current working type
AC、A、A-SI
Rated current
25、40、63A
Poles
1P+N, 3P+N
Rated voltage Ue
1P+N:240V~ 3P+N:415V~
Insulation voltage Ui
500V
Rated frequency
50/60Hz
Rated sensitivity I△n
10、30、100、300mA
Rated residual making and breaking capacity I△m
500A(below 63A) 10In(63A and above)
Short-circuit current Inc= I△c
6000A
Break time underIan
≤0.1S
Rated impulse withstand voltage(1.2/50)Uimp
4000V
Dielectric test voltage at and ind.Freq.for 1min
2.5kV
Electrical life and Mechanical life
4000
Pollution degree
2
Installation
Fault current indicator
NO
Protection Class
IP20
Ambient temperature(with daily average≤35℃)
-25℃+40℃
Storage temperature
-25℃+70℃
Terminal connection type
Cable/U-type busbar/Pin -type busbar
Wiring size(Cord/Hoop Terminals)
25mm²
Tightening torque
3.0N*m 22
Mounting
On DIN rail FN 60715 (35mm)
by means of fast clip device
Connection
From top and bottom
Specification
Description
PCS/CTN
Carton Size
(CM)
G.W.
(KG)
N.W.
(KG)
16-25A
GYL8M 2P 30mA AC
100
49*40*17.5
20
19
32-40A
100
49*40*17.5
20
19
50-63A
100
49*40*17.5
20
19
116-25A
GYL8M 2P 100/300mA AC
100
49*40*17.5
20
19
32-40A
100
49*40*17.5
20
19
50-63A
100
49*40*17.5
20
19
16-25A
GYL8M 4P 30mA AC
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
16-25A
GYL8M 4P 100/300mA AC
50
49*40*17.5
20
19
32-40A
50
49*40*17.5
20
19
50-63A
50
49*40*17.5
20
19
