Home > Products > Circuit Breaker > GEYA GYR10NM Magnetic RCBO C65 2Pole 63A 30mA 100mA 300mA Factory Supply Earth Leakage Breaker with Overcurrent Protection
GEYA GYR10NM Magnetic RCBO C65 2Pole 63A 30mA 100mA 300mA Factory Supply Earth Leakage Breaker with Overcurrent Protection

GEYA GYR10NM Magnetic RCBO C65 2Pole 63A 30mA 100mA 300mA Factory Supply Earth Leakage Breaker with Overcurrent Protection

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Gyr10nm Magnetic Rcbo C65 2pole 63a 30ma 100ma 300ma Factory Supply Earth Leakage Breaker With Overcurrent Protection - Buy Magnetic Rcbo earth Leakage Breaker 2 Pole Earth Leakage Circuit Breaker Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

·······This link price is only for GYR10NM-Magnetic AC 2P 6-25A 30/100/300mA·······
GEYA GYR10NM Magnetic RCBO C65 2Pole 63A 30mA 100mA 300mA Factory Supply Earth Leakage Breaker with Overcurrent Protection
GEYA GYR10NM Magnetic RCBO C65 2Pole 63A 30mA 100mA 300mA Factory Supply Earth Leakage Breaker with Overcurrent Protection
GEYA GYR10NM Magnetic C65 RCBO 2Pole 63A 30mA 100mA 300mA Factory Supply Earth Leakage Breaker with Overcurrent Protection
General
item
value
Place of Origin
China

Zhejiang
Brand Name
GEYA
Model Number
GYR10NM
Type
Residual Current
Poles Number
2
Poles
2P 4P/Electronic or Magnetic Type
Rated working voltage
230V/400V
Rated Current
6A 10A 16A 20A 25A 32A 40A 63A
Residual Current
30mA,100mA,300mA
Available type
ACtype Atype
Instantaneous trip type
B Curve C Curve
Rated short-circuit Breaking Capability
6000A
Certificate
CE
Guarantee
2YEARS
Rated current (In)
6A,10A,16A,20A,25A,32A,40A,63A
Rated voltage (Un)
230VAC/240VAC
Breaking Capacity
4.5KA/6KA
Rated Tripping Current
30mA,100mA,300mA
Type
AC TYPE, A TYPE
Characteristic
B CURVE, C CURVE
Number of Poles
2POLE 4POLE
Terminal Capacity
cable up to 25mm²
Width
36mm/module, 72mm/module
Standards
IEC61009,EN61009
Items
Specifical
PCS/CTN (MOQ)
Dimension
N.W
G.W
L
W
H
2P Magnetic
AC type
6A-25A, 30mA/100mA/300mA
60
47*23.5*17.5
14
15
32A-40A, 30mA/100mA/300mA
60
47*23.5*17.5
14
15
2P Magnetic
A type
6A-25A,30mA/100mA/300mA
60
47*23.5*17.5
14
15
32A-40A,30mA/100mA/300mA
60
47*23.5*17.5
14
15
2P Electronic
AC type
6A-25A, 30mA/100mA/300mA
60
47*23.5*17.5
14
15
32A-40A, 30mA/100mA/300mA
60
47*23.5*17.5
14
15
2P Electronic
A type
6A-25A,30mA/100mA/300mA
60
47*23.5*17.5
14
15
32A-40A,30mA/100mA/300mA
60
47*23.5*17.5
14
15
4P Magnetic
AC type
6A-25A,30mA/100mA/300mA
30
52*25.5*20
12
13
32A-40A,30mA/100mA/300mA
30
52*25.5*20
12
13
4P Electronic
AC type
6A-25A,30mA/100mA/300mA
30
52*25.5*20
12
13
32A-40A,30mA/100mA/300mA
30
52*25.5*20
12
13
4P Electronic
A type
6A-25A,30mA/100mA/300mA
30
52*25.5*20
12
13
32A-40A,30mA/100mA/300mA
30
52*25.5*20
12
13
