Product Description

This link price is only for GYRC-ZN01-APE 2P/32A

GYRC-ZN01-PE is mainly suitable for AC rated frequency 50Hz, rated voltage not exceeding 440V, rated current not exceeding 100 A, and short circuit capacity not exceeding 10 K A; It can be installed in smart meter measurement systems, photovoltaic grid connection, industrial control, equipment, home, office buildings, street light control systems, nursing homes, cultural relics protection units, schools, hospitals, agriculture, gardens, and other distribution circuits. It has functions such as remote control, manual opening and closing, over temperature protection, over voltage/under voltage, over power, electrical energy measurement, overload, short circuit, ground fault protection, and leakage protection.It can also be used as a gateway, also known as a protocol converter, which is a complex network connection device that can support the conversion between different protocols and achieve interconnection between different protocol networks.

Product Features：
1. Maintenance safety lock: greatly ensuring the personal safety of maintenance personnel;
2. Anti theft cover plate: It can effectively prevent electricity theft, unauthorized pulling of wires, etc;
3. Independent power supply design: can effectively prevent the overall system from being paralyzed and unable to work;
4.1.3 inch OLED display screen design: providing a more intuitive human-machine operation interface for maintenance personnel;
5. Modular design: can be selectively paired and used more flexibly;
6. High accuracy: voltage and current detection accuracy is 0.5 level, and electricity accuracy is 1.0 level;
7. The overall function of the circuit breaker preserves the characteristics of the small circuit breaker;
8. It can flexibly choose communication methods and can also be used as a gateway;
9. Flexible selection of function shutdown, alarm, and trip protection methods;
10. Multiple remote upgrade modes, allowing users to upgrade and maintain without any hassle;
11. Power outage protection design: After the main circuit is powered off, it ensures that data is saved and uploaded without
loss;
12. Automatic judgment and analysis of fault causes and operational events, displaying logs for easy maintenance and
troubleshooting;
13. Timing switch function: ensuring equipment timing switch, ensuring energy consumption, and saving electricity;
14. The function of load imbalance, phase loss, phase mismatch, and over temperature protection greatly ensures the aging of
equipment and lines, and ensures the safety of electricity consumption;
15. The leakage protection is sensitive, and different leakage protection values can be set according to the usage environment.

Product Model	GYRC-ZN01-100AP-2P	GYRC-ZN01-100AP-4P	GYRC-ZN01-PE-2P	GYRC-ZNO1-PE-4P
Product meets standards	GB16917.1	GB16917.1	GB16917.1	GB16917.1
Product meets standards		CQG1149	CQC1149	CQG1149	GQG1149
Product appearance (length * width * height)	1217279mm	23.510879mm	1219079mm	123.512679mm
Specified voltage	230V	400V	230V	400V
Prescribed current level	32A、63、100A	32A、63、100A	32A、63、100A	32A、63、100A
Short circuit protection characteristics	C	C	C	G
Short circuit protection short-circuit capacity	6000A	6000A	6000A	6000A
Leakage protection action time	less than 0,1s	less than 0.1s	less than 0.1s	less than 0.1s
Mechanical life	Greater than 10000 times	Greater than 10000 times	Greater than 10000 times	Greater than 10000 times
Electrical lifespan	More than 6000 times	More than 6000 times	More than 6000 times	More than 6000 times
Protection level	lp20	lp20	lp20	lp20
Working environment speed	-40~70℃	-40~70℃	-40~70℃	-40~70°℃
Installation method	35mm standard guide rail	35mm standard guide rail	35mm standard guide rail	35mm standard guide rail
Closing and opening mode	Manual or remote closing and opening	Manual or remote closing and opening	Manual or remote closing and opening	Manual or remote closing and opening
Wiring capability	25square	25square	25square	25square
Function parameter setting method	Local+Remote Settings	Local+Remote Settings	Local+Remote Settings	Local+Remote Settings
Communication method	46(RJ45)+RS485	46(RJ45)+RS485	46(RJ45)+RS485	46(RJ45)+RS485

Type

Dimension

PCS/CTN

Inner box size

(CM)

Carton Size

(CM)

G.W.

(KG)

N.W.

(KG)

GYRC-ZN01

120.9*72*72.9

16.2*8.9*10.5

33*29*17

5.95

4.59

GYRC-ZN01

123.4*108*72.9

15.3*14*10.5

33*29*18

6.25

GYRC-ZN02

102.9*36*67.3

11*6*8.5

42.5*32*19

9.85

7.85

GYRC-ZN02

102.9*72*67.3

11*6*8.5

42.5*32*19

GYRC-ZN02

102.9*90*67.3

11*9.5*8.5

42.5*32*19

15.16

13.44

GYRC-ZN02

102.9*108*67.3

11*11*8.5

42.5*32*19

18.5

16.5

GYRC-ZN02L

111.7*72*67.3

13.2*7.8*8.5

42.5*32*19

16.1

15.1

GYRC-ZN02L

111.7*90*67.3

13.2*11.4*8.5

42.5*32*19

15.84

16.88

GYRC-ZN02L

111.7*108*67.3

13.2*11.4*8.5

42.5*32*19

19.2

20.24

GYRC-ZN03

89*36*73

9.8*5.6*8.3

42*29*18.5

8.5

GYRC-ZN03

89*54*73

9.8*5.6*8.3

42*29*18.5

14.6

13.1

GYRC-ZN03

89*72*73

9.8*9.3*8.3

42*29*18.5

10.9

GYRC-ZN03

89*90*73

9.8*9.3*8.3

42*29*18.5

15.3

13.8

GYRC-ZN05

101.9*36*67.3

11.8*22*8.5

60.2*23.2*18.5

14.1

12.6

Q:What advantages do you have? A: GEYA is the direct Mlanufacturer in Wenzhou China from 2007, we have professional developing, marketing & production team to offer you the most competitive price and best service. Q: What's your main product? A: We have two product projects, low voltage electrical and automation control items Q: Could you print our own logo? A: Yes, Our company is available for Retail & Wholesale & OEM & ODM. Q: How long is the product guarantee? A: 18 month warranty, have QC department in charge of the products quality, our products are 100% inspection. Q:What is your quality control process? A: The quality of our production depends on all the components and therefore when selecting our suppliers we have to pay more attention to the quality of the raw material supplied. To prevent possible errors we perform testing at different levels and intemmediate stages of the product production phases. Q: How long is the delivery time? A: lt usually takes about 3 - 5 working days for sample order and 10 - 25 days for big order. Q: What is your payment term? A: Our Payment term is T/T, Aliexpress, Western Union, PayPal, Money Gram, L/C at sight. Q: Any certification of your company or product? A: We have ISO 9001.CE.CB.SEMKO,SAA.TUV.CCC， ROHS
