Product Description

··············This link price is only for HGL-160/3P 125~160A············

HGL,HGLC series isolation switches,HGLZ series double-throw transfer isolation switches(hereinafter referred to as switches).Suitable for industrial enterprise distribution equipment with AC 50Hz,rated voltage upto 660V,DC voltage up to 440V,and resistive current (lth)up to 3200A,usedfor infrequent connection and disconnection of circuits and electricalisolation (above 1000A only used for electrical isolation),widely used indistribution systems and automation systems in construction,power,petrochemical and other industries.

Rated Thermal Current Ith (A					160	250	400	630	1000
Rated Insulation Voltage UI					800V			1000V
Dielectric Strength					3000V			3500V
Rated Impulse Withstand Voltage Uimp					8KV			12KV
Rated Operational Voltage Ue					AC400 660V
Rated Frequency					50Hz
Utilization Category					AC-21 22 23
Rated Operational Current le(A)	AC 400V	AC-21	160	250	400	630	1000
				AC-22	160	250	400	630	1000
				AC-23	160	250	400	630	800
		AC 660V	AC-21	160	250	400	630	1000
				AC-22	100	200	315	400	630
				AC-23	63	125	200	250	400
Rated Making Capacity(A Rms					10le
Rated Breaking Capacity(A Rms)					8le
Rated Short-Circuit Making Capacity Icm(kA Rms)					12	17	30	40	70
1S Short-Time Withstand Current Icw(kA Rms)					10	12	20	25	50
Mechanical Life(Times)					5000			3000			2000
Electrical Life(Times)					1000			600			300
Operating Torque (N ·m)					6.5	10	15			27
Weight kg (excluding handle)			3 Pole	1.1	1.7	4.0	4.6	11.1
Weight kg (excluding handle)				4 Pole	1.3	2.2	5.0	5.8	14.7
The main parameters of auxiliary switches					50Hz AC-15 230V 3A
