GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design

GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Safe-multi Safety Relay For Ac/dc 24 V +/- 10 % With Utilisation Category 5a Relay Output Redundant Circuit Design - Buy 100% Original And 100% Brand New Safety Relay Electrical Equipment Machine Protection And Safety protector Relay Safety Relay Excellent Quality slim Relay 220v Ac Safety Relay Attractive In Price And Quality Product on Zhejiang Geya Electrical Co., Ltd.

Send Inquiry

Product Description

···········This link price is only for SAFE-MULTI············
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
SAFE-MULTlis an all-purpose emergency stop device with seven safe relay contacts for safe monitoring of one or two channel sensors, certified by TUV Rheinland. Further applications for the SAFE-MULTlinclude single or dual channel emergency stop circuits and guard monitoring on machines and plants according to EN ISO 13849-1, EN 62061, and EN 61508. Features: 1. 7 non-delayed safety contacts 2. 4 auxiliary relays and 2 auxiliary 3. semiconductor outputs 4. Connection of: （1）Emergency stop buttons （2）Mechanical safety switches （3）Non-contact safety switches （4）Safety components with OSSD outputs 5. Control: single or dual channel 6. Feedback loop for external contractors or extension modules 7. Cyclical monitoring of the output contacts 8. LED indicator for power and status 9. Automatic or manual start 10. Short-circuit monitoring and ground fault monitoring 11. ​Up to PL e, SILCL 3, category 4 (EN ISO 13849-1, EN 62061, EN 61508)
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
GEYA SAFE-MULTI Safety Relay for AC/DC 24 V +/- 10 % with Utilisation Category 5A Relay Output Redundant Circuit Design
In compliance with
EN 60204-1; EN ISO 13849-1;IEC 62061
Operating voltage
AC/DC 24V+/-10%
Power consumption
AC 8.5 VA/DC 4.5 W
Rated supply frequency
50-60 Hz
Safety contacts
7 non-delayed safety contacts(NO)
Auxiliary contacts
4 non-delayed auxiliary contact (NC)
Auxiliary transistor outputs (O1, O2)
DC 24 V/30 mA, over current protected
Max.switching voltage
AC 250V
Contact rating of safety contacts (13-14,…,73-74)6 switching cycles/ min
AC: 250 V,2000 VA,8A for resistive load 250 V.3AforAC-15
DC:30 V,240 W,8A for resistive load 24V,3Afor DC-13
Max. total current through all 7 contacts up to Ta=40 ℃:
35 A with 10 mm spacing between the devices
20 A no spacing between the devices
Contact rating of auxiliary contact
AC: 250 V,2000 VA,8A for resistive load
DC: 40 V,320 W,8 A for resistive load
Minimum contact load
5V,10 mA
External fuses
10A gG(NO);6A gG (NC)
Max.switch-on delay
<30 ms
Max.switch-off delay
Via S12 or S13/S14<20 ms
Recovery time
< 500 ms
Max. length of control line
2x1000 m at 1.5 mm2,2x500 m at 0.75 mm2
Wire width
0.14-2.5 mm²
Tightening moment (Min./Max.）
0.5 Nm/0.6 Nm
Contact material
AgSnO2
Service Life
mech.approx.1x107
Rated impulse withstand voltage, leakage path/air gap
4 kV (DIN VDE 0110-1)
Rated insulation voltage
250V
Degree of pollution/Overvoltage category
2/3(DIN VDE 0110-0)
Protection
IP20
Temperature range Ambient
15 ℃ to +40 ℃
Temperature range Storage
15℃ to +85℃
Max.altitude
≤ 2000 m (above sea level)
Weight approx.
350g
Mounting DIN rail according to EN 60715
TH35
Product Name
PCS/CTN
N.W of product (g)
G.W of product (g)
Carton Size
(CM)
N.W.
(KG)
G.W.
(KG)
SAFE-ESTOP
50
160
185
41*35*20
10
9
SAFE-ESTOP 50 (50 pcs/box)
50
160
160
41*35*20
10
9
SAFE-DELAY
50
225
250
41*35*20
13
12
SAFE-TWO-HAND
50
155
180
41*35*20
10
9
SAFE-SIL
50
175
200
41*35*20
11
10
SAFE-SIL (50 pcs/box)
50
175
175
41*35*20
11
10
SAFE-MULTI
25
315
400
41*35*20
11
10
