Product Description

············This link price is only for GYC1-G225 100-250V AC\DC···········

GYC 1-G225 AC contactor (hereinafter referred to as contactor) is mainly used for AC-4 / AC-3, AC 50Hz (or 60Hz), rated 400V rated working voltage, AC 50Hz (or 60Hz), rated working voltage of 1140V and 330A rated AC circuit of AC-01.

Features：

1.Intelligent

Equipped with real-time "health" monitoring function, enabling monitoring and protection of main circuit current and temperature.

Equipped with RS-485 communication function.

Integrated structure with built-in protection function of electronic thermal relay.

2.Excellent Performance

Performance improved by 90% (compared to F series).

High making and breaking capacity, along with short-time withstanding capability.

Able to meet more extensive and demanding requirements.

3.Diversified Energy-saving Control

Dual-coil control: 220V, 380V, etc.

voltage control: 100-250V, 48-130V, 200-500V, etc.

4.Compact Size

Volume reduced by 40% (compared to F series).

Supports side-by-side installation, improving cabinet space utilization effectively.

5.Convenient Installation

Compatible with Giga installation dimensions, can be directly connected to circuit breakers.

Equipped with quick-connection terminals.

6.Simple Maintenance

Inverted structure for simpler maintenance of wear-prone parts.

Can be directly replaced from the front, no need to reserve space on the side.

Model			GYC1-G225
Rated working current is IeA Ue 440V	AC-3/AC-4 θ≤60℃	225
Rated working current is IeA Ue 440V		AC-1 θ≤40℃	330
Convened free-air heating current IthA			330
Rated insulation voltage :UiV			1250
Rated impact withstand voltage of Uimp KV			12
Rated connection ability			On current:10 I (AC-3) or 12 I （AC-4）
Rated score and break ability			Breaking current: 8 I (AC-3) or 10 I (AC-4)
The short-time tolerance current starts from the cold state, with no current for 60 minutes and a ring temperature of 40℃	10 second	1800
		30 second	1000
		1 minute	850
		3 minute	560
		10 minute	440

Geya is a high-tech private enterprise focusing on the independent research and development of low-voltage electrical appliances and automation control intelligent products.High-tech enterprise in Zhejiang Province.The company's sales revenue has reached over 100 million RMB in 2023.Comprehensively advancing towards automated production. Continuously meeting customer delivery requirements.Our primary task is to meet customer needs. We will deliver products with zero defects in a timely manner.Our main categories are low-voltage products, industrial control products, and photovoltaic products, such as relays, circuit breakers, and DC fuses.All types of certificates are complete, such as CE CB, etc.

Q:What advantages do you have? A: GEYA is the direct Mlanufacturer in Wenzhou China from 2007, we have professional developing, marketing & production team to offer you the most competitive price and best service. Q: What's your main product? A: We have two product projects, low voltage electrical and automation control items Q: Could you print our own logo? A: Yes, Our company is available for Retail & Wholesale & OEM & ODM. Q: How long is the product guarantee? A: 18 month warranty, have QC department in charge of the products quality, our products are 100% inspection. Q:What is your quality control process? A: The quality of our production depends on all the components and therefore when selecting our suppliers we have to pay more attention to the quality of the raw material supplied. To prevent possible errors we perform testing at different levels and intemmediate stages of the product production phases. Q: How long is the delivery time? A: lt usually takes about 3 - 5 working days for sample order and 10 - 25 days for big order. Q: What is your payment term? A: Our Payment term is T/T, Aliexpress, Western Union, PayPal, Money Gram, L/C at sight. Q: Any certification of your company or product? A: We have ISO 9001.CE.CB.SEMKO,SAA.TUV.CCC， ROHS
