GEYA China Manufacturer Lithium Battery Energy Storage System Solar Hybrid Inverter-100kw 6kVA 10KVA Solar Power Inverter

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya China Manufacturer Lithium Battery Energy Storage System Solar Hybrid Inverter-100kw 6kva 10kva Solar Power Inverter - Buy China Manufacturer Lithium Battery Energy Storage System Solar Hybrid Inverter-100kw Solar Power Inverter With Battery Charger china Off Grid Inverter china Solar Power Inverter Product on Zhejiang Geya Electrical Co., Ltd.

Product Description

This price link is only for REVO VM III 5000-48 inverter

Flexibility
1. Suitable for all kinds of pumps, including single-phase 220V pump
2. Compatible with all popular solar panels
3. Support AC input could switch to grid power supply to make the system work 24 hours

Smartness
1. Built-in MPPT technology with up to 99% efficiency
2. With water level detection function, automatically regulate the pump flow to prevent dry-running, full water level, etc.
3. Self-adaptation to the motor’s power rating

High Cost-effectiveness
1. Plug-and-play system design, no need to set any parameter
2. Wide range of input voltage
3. No need battery, suitable for all kinds of applications
4. Easy installation and effortless maintenance

Reliability
1. 10-year market-proven experience of leading motor and pump drive technology
2. Soft start feature to prevent water hammer and increase system life
3. Built-in overvoltage. overload, Undervoltage, and weak sunshine protection

Remote Monitoring
1. Standard RS485 interface, support to remote monitor the system with MICNO software on PC
2. Optional GPRS module for remote monitoring
3. Spots value of solar pump parameters monitoring available from anywhere
4. Support the lookup of the history parameters of the solar pump system

Model：3-5.5kw
Nominal Voltage：230VAC
Frequency Range:50Hz/60Hz

* Output power factor PF=1.0 .
* Configurable AC/Solar Charger priority via LCD setting .
* Compatible with mains voltage or generator power.
* Overload, Over temperature, Short circuit protection.
* Integrated Bluetooth interface with Android App.
* Supports USB On-the-Go function.
* Reserved communication port (RS-485, CAN-BUS, or RS-232)for BMS.
* Battery independency.
* User-friendly LCD operation.
* Replaceable fan design.

Technical Data

MODEL	REVO VM III 3000-24	REVO VM III 5000-48
Rated Power	3000VA/ 3000W	5500VA/ 5500W
INPUT
Voltage	230 VAC
Selectable Voltage Range	170-280 VAC (For Personal Computers); 90-280 VAC(For Home Appliances)
Frequency Range	50Hz/60 Hz(Auto-sensing)
SOLAR CHARGER &AC CHARGER
Solar charger type	MPPT
Maximum PV Array Power	4000 W	5000 W
MPPT Range @ Operating Voltage	120~450 VDC
Maximum PV Array Open Circuit Voltage	500 VDC
Maximum Solar Charge Current	80A
Maximum AC Charge Current	60A
Maximum Charge Current	80A
BATTERY
Battery Voltage	24 VDC	48 VDC
Floating Charge Voltage	27 VDC	54 VDC
Overcharge Protection	33 VDC	63 VDC
OUTPUT
AC Voltage Regulation(Batt.Mode)	230VAC±5%
Surge Power	6000VA	10000VA
Efficiency (Peak)	up to 93.5%
Transfer Time	10 ms (For Personal Computers); 20 ms (For Home Appliances)
Waveform	Pure sine wave
PHYSICAL
Dimension,D xWx H(mm)	115 x300 x400
Net Weight (kgs)	9	10
Communication Interface	USB/RS232/RS485/Bluetooth/Dry-contact
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity (Non-condensing)
Operating Temperature	-10°C to 50℃
Storage Temperature	-15°C to 60℃

GEYA TEAM ONLINE

24hours
*6 Sales Manager

*20 Sales Assistant
* 5 Technical Engineer
*10 QC Inspector
*120 Professional Worker

GEYA Electrical is established in February 2007, with annual turnover more than 10 million dollars.Headquarters is based in Wenzhou, China.

In the past 12 years, GEYA was focusing on the low voltage electrical and automation control project research, development and production. The current products offers a wide range of low voltage electrical and automation control items including ACB, MCB, MCCB, RCCB, Contactor, Inverter, Solar Energy System, Time Relay, Control Relay, Voltage Relay, PLC Relay Module, Timer Switch, Distribution boxes and other related accessories and components.
GEYA products are certified to required industry standards, with approvals according to ROHS, ISO9001, CCC, CE, CB, SAA, SEMKO, TUV, EN. In addition to providing OEM&ODM service for our worldwide customers, we also welcome our customers to distributor our brand to overseas market, and we will provide our customers more competitive sales policies.
Today, GEYA sales area covers 6 continents, with more than 1000 foreign companies purchasing products from us. There is no doubt we will be promoting our products to more countries.
Our belief is Modernization - Accuracy - Reliability - Quality - Customer Satisfaction.
