Product Description

···········This link price is only for AX300-004G/5R5P-T4 380V/4KW············

1 Built-in MPPT function and efficiency up to 99.6% 2 Could drive both AM and PMSM pump 3 Advanced software technology and perfect in driving PMSM pump 4 Perfect stability in output frequency 5 Remote control and monitoring by GPRS system(Available in PC and mobile) 6 Dry run function to protect the pump 7 Automatic start and stop function 8 DC and AC as input power sources accepted 9 Low voltage input down to 60VDC input for 110V/220V pump solution

Recommended MPPT voltage range	Vmpp 280 to 375VDC for 2S model ( 150V to 450VDC input, 3PH 220 to 240VAC output)
Recommended MPPT voltage range		Vmpp 486 to 750 VDC for 4T model ( 250V to 800VDC input, 3PH 380 to 440VAC output)
Recommended input voltage (Voc and Vmpp)	Voc 355V DC, Vmpp 310V DC for 2S model or 220V AC pumps
Recommended input voltage (Voc and Vmpp)		Voc 620V DC, Vmpp 540V DC for 4T model or 380V AC pumps
Motor type	Control for permanent magnet synchronous motor(PMSM) and asynchronous motor(AM)
Input power	DC power from solar arrays or AC grid power
Maximum DC power input	450VDC for 220V AC Pump / 800VDC for 380V AC Pump
Rated output voltage	3-phase 220V or 3-phase 380V/440V
Output frequency range	0-50/60Hz
MPPT efficiency	99.60%
Ambient temperature range	-10℃ TO 50℃
Solar pump control special performance	MPPT ( maximum power point tracking), CVT (constant voltage tracking),auto/manual operation, dry run protection, low stop frequency protection, minimum power input, motor maximum current protection, flow calculating, energy generated calculating
Protection function	Phase loss protection, phase short circuit protection, ground to phase circuit protection, input and output short circuit protection. Stall protection
Protection degree	IP20-Air force cooling
Running mode	MPPT,CVT, variable frequency mode
Altitude	Below 1000m; above 1000m, derated 1% for every additional 100m
Standard	CE certificate.Design based on vector control inverter
