Product Description

·········This link price is only for DC-PV2 without cable gland··········

Generally speaking, the voltage on the DC side of a photovoltaic system is usually high, up to 1000 VDC.Therefore.we need a switchgear with Ue=1000VDC. The branch in the combiner box needs to be protected, confluence main circuit equipment in the box and DC cabinet requires isolation function 1. With 1000VDC load switching or remote operation function. In addition, it is necessary to install switchgear 2 and the load on the DC side of the inverter cabinet switchover to provide isolation for maintenance.

Product Features：

Each pole contact is equipped with an arc extinguishing system that can extinguish the arc immediately when the switch is closed. ●UV-resistant IP66 housing ●Extremely short power-off time of about 2ms ● The cover is removable only in the "closed" position ● Ground terminal ● IEC60947-3,AS/NZS60947.3:2015 ●DC-PV1DC-PV2DC-21B ●10A-32A DC1200V ●Convenient installation

Items	Specifical
Items	Specifical
without cable gland	DC1000V/32A
with cable gland	DC1000V/32A
Basic	DC1000V/32A
Upgraded	DC1000V/32A
Two in two out (with wire)	DC1000V/32A
Two in two out (MC4)	DC1000V/32A
Built-in isolation switch	DC1000V

Rated voltage	1000VDC~1200VDC
IP rating	IP66
line type	M20 M25 MC4
Rated current	10A,16A,20A,25A,32A
Working temperature	-25℃~+85℃
Standard	IEC60947-3,AS/NZS60947.3:2015
