Model | GYA-256100 | GYA-512100 | |
Standard Voltage | 25.6VDC | 51.2VDC | |
Voltage Range | 21.6~ 28.8VDC | 43.2~ 57.6VDC | |
Norminal Capacity | 100Ah | 100Ah | |
Rated Energy | 2.56kWh | 5.12kWh | |
Communication | CAN / RS485 / RS232 / WIFI / Blue Tooth | ||
Cell Self-Discharge | <5 % / Month | ||
Modules Connection | 1~15 in Parallel | ||
DOD | 90% | ||
Cycle Life | ≥ 6000 @ 25℃,80% DOD | ||
≥ 6000 @ 25℃,80% DOD | 100A | ||
Ingress Protection | IP20 | ||
Installation | Cabinet or Wall | ||
Working Temperature | 0~55 ℃ | ||
Storage Temperature | -20~55 ℃ | ||
Humidity | ≤ 80% | ||
Product Dimenstion | 484*330*165mm | 484*425*176.5mm | |
Package Dimenstion | 545*430*285mm | 545*510*300mm | |
Net Weight | 24kg | 41kg |
