Product Description

············This link price is only for GYM9H-DC 1P 6KA 50A-63A···········

GYM9H-DC DC circuit breaker is used for DC voltage up to 1000V rated current up to 63A for overload and short circuit protection, and it can also, be used for infrequent operation conversion of the line. It is suitable for DC system applications such as communication and photovoltaic systems. Compliant with: GB 14048.2, IEC 60947-2 Product Features: double busbars, transparent logo, quick closing function, and independent appearance patent.

Electrical features
Rated current	1-63A
Poles	1P 2P 3P 4P
Rated voltage Ue	1P:250V DC 2P:500V DC 3P:750V DC 4P:1000V DC
Rated breaking capacity	6000A
Rated impulse withstand voltage(1.2/50) Uimp	6kV
Polution degree	2
Thermo-magnetic release characteristic	B:5.5In±20%; C:8.5In±20%
Mechanical life	10000
Installation
Contact position indicator	Yes
Protection Class	IP20
Reference temperature for setting of thermal element	30℃
Ambient temperature(with daily average≤35℃)	-25℃+60℃
Storage temperature	-25℃+70℃
Terminal connection type	Cable/U-type busbar/Pin -type busbar
Wiring size (Copper/Hard Wire)	25mm²
Tightening torque	3.0N*m 22
Mounting	On DIN rail FN 60715 (35mm) by means of fast clip device

GEYA TEAM ONLINE

24hours
*6 Sales Manager

*20 Sales Assistant
* 5 Technical Engineer
*10 QC Inspector
*120 Professional Worker

GEYA Electrical is established in February 2007, with annual turnover more than 10 million dollars.Headquarters is based in Wenzhou, China.

In the past 12 years, GEYA was focusing on the low voltage electrical and automation control project research, development and production. The current products offers a wide range of low voltage electrical and automation control items including ACB, MCB, MCCB, RCCB, Contactor, Inverter, Solar Energy System, Time Relay, Control Relay, Voltage Relay, PLC Relay Module, Timer Switch, Distribution boxes and other related accessories and components.
GEYA products are certified to required industry standards, with approvals according to ROHS, ISO9001, CCC, CE, CB, SAA, SEMKO, TUV, EN. In addition to providing OEM&ODM service for our worldwide customers, we also welcome our customers to distributor our brand to overseas market, and we will provide our customers more competitive sales policies.
Today, GEYA sales area covers 6 continents, with more than 1000 foreign companies purchasing products from us. There is no doubt we will be promoting our products to more countries.
Our belief is Modernization - Accuracy - Reliability - Quality - Customer Satisfaction.
