MODEL | REVO VM IV 8000-48 |
Rated Power | 8000VA/8000W |
INPUT | |
Voltage | 230 VAC |
Selectable Voltage Range | 170-280 VAC (For Personal Computers);90-280 VAC (For Home Appliances) |
Frequency Range | 50 Hz/60 Hz(Auto sensing) |
OUTPUT | |
AC Voltage Regulation(Batt. Mode) | 230VAC±5% |
Surge Power | 16000VA |
Effciency(Peak) | up to 93.5% |
Transfer Time | 10 ms (For Personal Computers);20 ms(For Home Appliances) |
Waveform | Pure sine wave |
BATTERY | |
Battery Voltage | 48 VDC |
Floating Charge Voltage | 54 VDC |
Overcharge Protection | 60 VDC |
SOLAR CHARGER & AC CHARGER | |
Maximum PV Array Open Circuit Voltage | 450VDC |
Maximum PV Array Power | 4000W*2 |
MPPT Range @ Operating Voltage | 120~450 VDC |
Maximum Solar Charge Current | 120A |
Maximum AC Charge Current | 120A |
Maximum Charge Current | 120A |
PHYSICAL | |
Dimension, DxWxH(mm) | 420X561.6X152.4 |
Net Weight (kgs) | 21 |
Communication Interface | USB/RS232 |
ENVIRONMENT | |
Humidity | 5% to 95% Relative Humidity (Non-condensing) |
Operating Temperature | -10°C to 50°C |
Storage Temperature | -15°C to 60°C |
