Electrical features | ||
Rated current | 1-63A | |
Poles | 1P 2P 3P 4P | |
Rated voltage Ue | 240/415V | |
Insulation voltage Ui | 500V | |
Rated frequency | 50/60Hz | |
Rated breaking capacity | 4.5kA | |
Rated impulse withstand voltage(1.2/50)Uimp | 4kV | |
Dielectric test voltage at and ind.freq.for 1min | 2kV | |
Polution degree | 2 | |
Thermo-magnetic release characteristic | B C D | |
Electrical life | 4000 | |
Mechanical life | 10000 | |
Installation | ||
Contact position indicator | Yes | |
Protection Class | IP20 | |
Reference temperature for setting of thermal element | 30℃ | |
Ambient temperature (with daily average≤35℃) | -25℃+40℃ | |
Storage temperature | -25℃+70℃ | |
Terminal connection type | Cable/U-type busbar/Pin -type busbar | |
Wiring size(Copper/Hard Wire) | 1-25mm² | |
Tightening torque | 3.0N*m 22 | |
Mounting | On DIN rail FN 60715 (35mm) by means of fast clip device | |
Connection | Top and bottom | |
Combination with accessories | ||
Auxillary contact | Yes | |
Alarm contact | Yes | |
Shunt release | Yes | |
Under voltage release | Yes | |
