GEYA GSP9-C40-3P-40KA Din Rail Mounted Class B 60KA Lightning Arrester SPD protection AC Surge Arrester Prices

#detail_decorate_root .magic-0{vertical-align:top}#detail_decorate_root .magic-1{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px}#detail_decorate_root .magic-2{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px}#detail_decorate_root ......Keywords:Geya Gsp9-c40-3p-40ka Din Rail Mounted Class B 60ka Lightning Arrester Spd Protection Ac Surge Arrester Prices - Buy Class B 60ka Lightning Arrester spd Protection surge Arrester Prices Product on Zhejiang Geya Electrical Co., Ltd.

Product Description

·············This link price is only for GSP9-C40-3P-40KA-275V·············

GSP9 series surge protective device (SPD) is suitable for TN-S TN-C-S TT IT etc. power supply system of AC 50/60Hz, 380V, installed on the joint of LPZ1 or LPZ2 and LPZ3, it's designed according to IEC61643-1 GB18802.1, it adopts 35mm standard rail, there is a failure release mounted on the module of surge protective device.

When the SPD fails in breakdown for over-heat and over-current, the failure release will help electric device separate from the power system and give the indication signal, green means normal, red means abnormal, it's also could be replaced for the module when has operating voltage.

The combination lightning current and surge arrestors meet the type 1+2 requirement class according to IEC 61643-1. These devices protect low-voltage consumer systems from overvoltages of all types and are available in single-pole to four-pole versions. The use of high-performance varistors permits a rapid response time and a low protection level, without any line follow current. If circumstances are uncertain and there is a risk of fire from an overload, the internal cut-off unit disconnects the arrestor from the mains if necessary. In addition, the QR code printed on the arrestor allows direct access to the online installation instructions.

Product Features
+ Connectable lightning current and surge arrestors
+ High arresting capacity up to 50 kA (10/350μs)
+ Visual status display
+ Available with optional remote signalling
+ Vibration-proof
+ Combination arrestors for buildings with lightning protection
+ Simple standard hat rail mounting
+ Labelled connections
+ Usable in systems with lightning protection class 3+4

SPD classification according to EN61643-11	Type 1+2
SPD classification according to IEC61643-11	Class II
Max. continuous operating a.c. voltage (L-N) Uc	275V
Max. continuous operating a.c. voltage (N-PE) Uc	255V
Lightning impulse current (10/350p s) limp	12.5kA
Norminal discharge current (8/20 p s) In	20kA
Max. discharge current (8/20 y s) (L-N) Imax	50kA
Max. discharge current (8/20 p s) (N-PE) Imax	80kA
Voltage protection level Up	≤1.3kV
Voltage protection level 5kA Up	≤1.1kV
Max. backup fuse	160A gL
Response time tA	≤25nx
Operating temperature range Tu	-40℃-80℃
Operating state/fault indication	green/red
Cross-section area (Min.)	6 mm²
Cross-section area(Max.)	35mm²
For mounting on	35mm Din rail
Enclosure material	Thermalplastic UL94-V0
Degree of protection	IP20
