Product Description

·············This link price is only for GSP9-DP20 2P··········

Application This AC Surge protective device is applied low voltage standardIEC/EN 61643-11 to protect against AC power line system andother equipment from over voltage and instant aneous over voltagedamage. It has advantages of large discharge current ,fastrespond time and low residual voltage.

Main Features 1.High discharge capadity.quick response,pluggable. 2. Fast response time ,din rail installation. 3. Double thermal disconnection devices, providing more reliableprotection. 4. Green window means normal ,red means defect ,need tochange module. 5. Remote alarm terminal optional. 6.Voltage can be customized.

Model	GPS9-DP20/GPS9-DP40
Test standard	IEC 61643-11; GB 18802.11
SPD type	T2/Class II
Maximum continuous operating voltage Uc	275V AC
Nominal discharge current(8/20μs)	20kA
Max. discharge current(8/20μs)	40kA
Voltage protection level Up	≤1.5kV
Response time Ta	25ns
Poles	2P, 4P, 1P+N-PE, 3P+N-PE
Matched fuse or circuit breaker	32A
Connection wire specifification	4mm^2 (L/N);6mm^2 (PE)
Mounting	35mm Din Rail
Type of remote signaling contact(Optional)	C+NC:Normally closed
		C+NC:Normally open
		C:Common contact
Switching capacity	AC:250V/0.5A DC:250V/0.1A, 125V/0.2A,75V/0.5A
Cross-sectional area for remote signal contact	Max.1.5mm^2 soild / f lexible
Operating temperature range	-40℃to+85℃
Shell material	UL94-V0 fifireproof material
