Product Description

*****this link price is only for GSP9-C40PV 600V 2P, if you need other Specifications， please feel free to contact us！*****

Application： This DC surge protective device is applied low voltage standard IEC EN 61643-11 to protect against DC power line system and other equipment from over-voltage and instantaneous over-voltage damage. Widely used in photovoltaic comber box, power inverter, DC distribution cabinet, etc. It has the advantages of a large discharge current, fast response time, and low residual voltage. Max. PV voltage up to UCPV ≤1000V dc. Main features: 1. High discharge capacity, quick response, module pluggable; 2. Fast response time, din rail installation; 3. Double thermal disconnection devices, provide more reliable protection; 4. Green window means normal, red means defect, need to change module; 5. Remote alarm terminal optional. 6. T1+T2 surge protection.

600V DC SPD DATASHEET:

Type
SPD according to EN 61643-31 / IEC 61643-31	type 1+2 / class I+II
Max. continuous operating DC voltage	600 V DC
(DC+)-PE,(DC-)-PE ,(DC+)-(DC-) Ucpv	600 V DC
Nominal discharge current (8/20μs) In	20 kA
Maximum discharge current (8/20μs) Imax	40 kA
Maximum impulse current (8/20μs) Itotal	40 kA
Maximum impulse current (10/350μs) Iimp	6.25 kA
Maximum impulse current (10/350μs) Itotal	12.5 kA
continuous current for PV application ICPV	0.2 mA
Voltage protection level (DC+)-PE,(DC-)-PE (DC+)-(DC-) Up	2.2 kV
Response time tA	25 ns (L-N)
Short-Circuit Current Rating Iscpv	2000 A
Residual current a.c. and d.c. IPE	0.3 mA(DC), 0.3 mA(AC),
Humidity range	5% ... 95%
Range of operating temperatures TU	-40°C ... +70°C
Atmospheric pressure and altitude	80k Pa ... 106k Pa,
Atmospheric pressure and altitude		-500 m ... 2000 m
Operating state / fault indication	Green ok / Red defect
Number of ports	One port
Cross-sectional area (max.)	2 AWG (Solid, Stranded) / 4 AWG (Flexible)
Cross-sectional area (max.)		35 mm2 (Solid, Stranded) / 25 mm2 (Flexible)
For mounting on	35 mm DIN rail acc. to EN 60715
Enclosure material	thermoplastic
Place of installation	indoor installation
Degree of protection	IP 20
Capacity	4 module(s), DIN 43880
Approvals	-
Type of remote signalling contact	changeover contact
a.c. switching capacity	250V / 0.5 A
d.c. switching capacity	250V / 0.1 A; 125 V / 0.2 A; 75 V / 0.5 A
Cross-sectional area for remote signalling	max. 1.5 mm2 solid / flexible
terminals	max. 1.5 mm2 solid / flexible
Remote signalling alarming mode	Normal: closed;
Remote signalling alarming mode		failure: open-circuit
Acessibility	Inaccessible
Protection fuction	Overcurrent
PV earthing system	Earthed and Unearthed (both)
SPD failure mode (OCFM/SCFM)	OCFM

1000V DC SPD DATASHEET:

Kind of Equip.:	Surge Protector (Surge Protective Device)
Location category:	Indoor
Number of ports:	One port
Method of mounting:	Fixed, 35 mm DIN rail acc. to EN 60715
Max. backup fuse	/
Short-circuit current rating(ISCPV)	2 kA
Residual Current(IPE)	DC 0.3 mA; AC 0.3 mA
Type of current:	AC
Test Class:	T1+T2
Nominal discharge current(In):	20kA
Max. discharge current (Imax):	40kA
Max. impulse current (Iimp)	6.25 kA
Total discharge current for Mutipole SPD(Itotal)	12.5 kA(10/350); 40 kA(8/20)
Max. continuous operation voltage (Ucpv):	DC 1000V
continuous current for PV application ICPV:	0.2 mA
Voltage protect level (Up):	3.6 kV
Modes of protection	+ to -, + to PE, - to PE
Application system	PV system(Earthed and Unearthed (both))
IP code	IP 20
Temperatures/humidity	-40 ℃ to +70 ℃， 5 % to 95 %
Remark:	OCFM

1500V DC SPD DATASHEET:

Type
SPD according to EN 61643-31 / IEC 61643-31	type 1+2 / class I+II
Max. continuous operating DC voltage	1500 V DC
(DC+)-PE,(DC-)-PE ,(DC+)-(DC-) Ucpv	1500 V DC
Nominal discharge current (8/20μs) In	20 kA
Maximum discharge current (8/20μs) Imax	40 kA
Maximum impulse current (8/20μs) Itotal	40 kA
Maximum impulse current (10/350μs) Iimp	6.25 kA
Maximum impulse current (10/350μs) Itotal	12.5 kA
continuous current for PV application ICPV	0.2 mA
Voltage protection level (DC+)-PE,(DC-)-PE (DC+)-(DC-) Up	5.0 kV
Response time tA	25 ns (L-N)
Short-Circuit Current Rating Iscpv	2000 A
Residual current a.c. and d.c. IPE	0.3 mA(DC), 0.3 mA(AC),
Humidity range	5% ... 95%
Range of operating temperatures TU	-40°C ... +70°C
Atmospheric pressure and altitude	80k Pa ... 106k Pa,
Atmospheric pressure and altitude		-500 m ... 2000 m
Operating state / fault indication	Green ok / Red defect
Number of ports	One port
Cross-sectional area (max.)	2 AWG (Solid, Stranded) / 4 AWG (Flexible)
Cross-sectional area (max.)		35 mm2 (Solid, Stranded) / 25 mm2 (Flexible)
For mounting on	35 mm DIN rail acc. to EN 60715
Enclosure material	thermoplastic
Place of installation	indoor installation
Degree of protection	IP 20
Capacity	4 module(s), DIN 43880
Approvals	-
Type of remote signalling contact	changeover contact
a.c. switching capacity	250V / 0.5 A
d.c. switching capacity	250V / 0.1 A; 125 V / 0.2 A; 75 V / 0.5 A
Cross-sectional area for remote signalling	max. 1.5 mm2 solid / flexible
terminals	max. 1.5 mm2 solid / flexible
Remote signalling alarming mode	Normal: closed;
Remote signalling alarming mode		failure: open-circuit
Acessibility	Inaccessible
Protection fuction	Overcurrent
PV earthing system	Earthed and Unearthed (both)
SPD failure mode (OCFM/SCFM)	OCFM
