Product Description

00:00

·············This link price is only for GSP9-D20-2P-20KA-275V·············

Application This AC surge protective device is applied low vollage standardIEN 61643-1i to protect against AC power line system and otherequipment from over voltage and instantaneous over voltagedamage.It has advantages of large discharge curent ,fast respondtime and kow residual voltage.

Main Features 1.High discharge capacity,qulck response,pluggable. 2.Fast response time,din rail installation. 3.Double thermal disconnection devices,prowiding more reliableprotection. 4.Green window means nomal red means defect,need tochange module. 5.Remote alarm terminal optional. 6.Voltage can be customized. 7.Class ll type 2 surge prdtection.

Model	GPS9-D20
Test standard	IEC/EN61643-11;GB18802.11
SPD type	T2/Class ll
Max.AC operating voltage(Uc)	275V/385VAC
Nominal discharge current(8/20μs)	10kA
Max.discharge current(8/20μs)	20kA
Voltage protection level Up	≤1.5kV(275V AC)
Voltage protection level Up		≤1.8kV(385V AC)
Response time Ta	25ns
Poles	1P 2P 3P 4P 1P+N-PE 3P+N-PE
Matched fuse or circuit breaker	32A
Connection wire specification	4mm²(L/N);6mm²(PE)
Method of installation	35mm Din Rail
Type of remotesignaling contact(Optional)	C+NC:Normally closed
		C+NC:Normally open
		C:Common contact
Max.Voltage/Current for remote	1A/2A/3A 125V AC
Wiring for remote signaling	1.5mm²max.
Operating temperature	-40℃ to +85℃
Shell material	UL94-VO fireproof material

Geya is a high-tech private enterprise focusing on the independent research and development of low-voltage electrical appliances and automation control intelligent products.High-tech enterprise in Zhejiang Province.The company's sales revenue has reached over 100 million RMB in 2023.Comprehensively advancing towards automated production. Continuously meeting customer delivery requirements.Our primary task is to meet customer needs. We will deliver products with zero defects in a timely manner.Our main categories are low-voltage products, industrial control products, and photovoltaic products, such as relays, circuit breakers, and DC fuses.All types of certificates are complete, such as CE CB, etc.
